Home / Power Supplies / FSP Hydro G PRO ATX3.0(PCIe5.0) 850W power supply unit 20+4 pin ATX ATX Black
FSP · MPN PPA8501914 · FSP Hydro G PRO ATX3.0(PCIe5.0) 850W power supply unit 20+4 pin ATX ATX Black
FSP Hydro G PRO ATX3.0(PCIe5.0) 850W power supply unit 20+4 pin ATX ATX Black
- Total Power
- 850 W
- 80 Plus Certification
- 80 PLUS Gold
- Purpose
- PC
- Cooling Type
- Active
- Fan Diameter
- 12 cm
- Fan Location
- Top
Specifications
Design
| Cooling Type | Active |
|---|---|
| Fan Diameter | 12 cm |
| Fan Location | Top |
| Number Of Fans | 1 fan(s) |
| On/Off Switch | Yes |
| Product Colour | Black |
Logistics data
| Harmonized System (Hs) Code | 84733020 |
|---|---|
| Warranty Period | 10 year(s) |
Operational conditions
| Operating Temperature (T-T) | 0 - 50 °C |
|---|
Packaging content
| Cables Included | CPU, PCIe, Peripheral (Molex), SATA |
|---|
Performance
| 80 Plus Certification | 80 PLUS Gold |
|---|---|
| Atx Version | 3.0 |
| Bearing Technology | FDB |
| Eps Version | 2.92 |
| Mean Time Between Failures (Mtbf) | 100000 h |
| Power Supply Unit (Psu) Form Factor | ATX |
| Purpose | PC |
Ports & interfaces
| Cabling Type | Fully-Modular |
|---|---|
| Cpu Power Cable Length | 70 cm |
| Cpu Power Connector (4+4 Pin) | Yes |
| Floppy Disk Drive Connector | Yes |
| Floppy Drive Power Connector | 1 |
| Motherboard Power Cable Length | 60 cm |
| Motherboard Power Connector | 20+4 pin ATX |
| Number Of Sata Power Connectors | 14 |
| Pci Express Power Connectors (12+4 Pin) | 1 |
| Pci Express Power Connectors (12+4 Pin) Cable Length | 700 mm |
| Pci Express Power Connectors (6+2 Pin) | 6 |
| Peripheral (Molex) Power Connectors (4-Pin) | 3 |
| Sata Power Cable Length | 500 mm |
Power
| Ac Input Frequency | 50/60 Hz |
|---|---|
| Ac Input Voltage | 100 - 240 V |
| Combined Power (+12v) | 850 W |
| Combined Power (-12v) | 3.6 W |
| Combined Power (+3.3v) | 120 W |
| Combined Power (+5v) | 120 W |
| Combined Power (+5vsb) | 12.5 W |
| Efficiency | 90% |
| Input Current | 11-5.5 A |
| Max Output Current (+12v) | 70.83 A |
| Max Output Current (-12v) | 0.3 A |
| Max Output Current (+3.3v) | 20 A |
| Max Output Current (+5v) | 20 A |
| Max Output Current (+5vsb) | 2.5 A |
| Power Factor Correction (Pfc) Type | Active |
| Power Protection Features | Over voltage, Over power, Over current |
| Total Power | 850 W |
Weight & dimensions
| Depth | 150 mm |
|---|---|
| Height | 86 mm |
| Width | 150 mm |
