Home / Power Supplies / Chieftec BDF-500S power supply unit 500 W 24-pin ATX PS/2 Black
Chieftec · MPN BDF-500S · Chieftec BDF-500S power supply unit 500 W 24-pin ATX PS/2 Black
Chieftec BDF-500S power supply unit 500 W 24-pin ATX PS/2 Black
- Total Power
- 500 W
- 80 Plus Certification
- 80 PLUS Bronze
- Purpose
- PC
- Cooling Type
- Active
- Fan Diameter
- 12 cm
- Fan Location
- Top
Specifications
Design
| Cooling Type | Active |
|---|---|
| Fan Diameter | 12 cm |
| Fan Location | Top |
| Number Of Fans | 1 fan(s) |
| On/Off Switch | Yes |
| Product Colour | Black |
Logistics data
| Harmonized System (Hs) Code | 84733020 |
|---|
Other features
| Warranty Card | Yes |
|---|
Packaging data
| Manual | Yes |
|---|---|
| Package Type | Box |
Performance
| 80 Plus Certification | 80 PLUS Bronze |
|---|---|
| Atx Version | 2.3 |
| Power Supply Unit (Psu) Form Factor | PS/2 |
| Purpose | PC |
Ports & interfaces
| Cabling Type | Non-Modular |
|---|---|
| Cpu Power Connector (4+4 Pin) | Yes |
| Motherboard Power Connector | 24-pin ATX |
| Number Of Sata Power Connectors | 6 |
| Pci Express Power Connectors (6+2 Pin) | 2 |
| Peripheral (Molex) Power Connectors (4-Pin) | 2 |
Power
| Ac Input Frequency | 50 - 60 Hz |
|---|---|
| Ac Input Voltage | 115 - 230 V |
| Combined Power (+3.3v) | 90 W |
| Combined Power (+5v) | 90 W |
| Efficiency | 85% |
| Max Output Current (+12v) | 41.68 A |
| Max Output Current (-12v) | 0.3 A |
| Max Output Current (+3.3v) | 18 A |
| Max Output Current (+5v) | 18 A |
| Max Output Current (+5vsb) | 2.5 A |
| Power Factor | 0.9 |
| Power Factor Correction (Pfc) Type | Active |
| Power Protection Features | Over voltage, Overload, Short circuit, Under voltage |
| Total Power | 500 W |
Weight & dimensions
| Depth | 140 mm |
|---|---|
| Height | 87 mm |
| Width | 150 mm |
