Home / Motherboards / ASUS TUF B360-PRO GAMING Intel® B360 LGA 1151 (Socket H4) ATX
ASUS · MPN 90MB0X00-M0EAY0 · ASUS TUF B360-PRO GAMING Intel® B360 LGA 1151 (Socket H4) ATX
ASUS TUF B360-PRO GAMING Intel® B360 LGA 1151 (Socket H4) ATX
- Motherboard Chipset
- Intel® B360
- Processor Socket
- LGA 1151 (Socket H4)
- Supported Memory Types
- DDR4-SDRAM
- Maximum Internal Memory
- 64 GB
- Ethernet Lan
- Yes
Specifications
BIOS
| Acpi Version | 6.1 |
|---|---|
| Bios Memory Size | 128 Mbit |
| Bios Type | UEFI AMI |
| Clear Cmos Jumper | Yes |
| Desktop Management Interface (Dmi) Version | 3.0 |
| System Management Bios (Smbios) Version | 3.1 |
Expansion slots
| Number Of M.2 (M) Slots | 2 |
|---|---|
| Pci Express X16 Slots | 2 |
| Pci Express X1 (Gen 3.X) Slots | 4 |
Features
| Audio Chip | Realtek ALC887 |
|---|---|
| Audio Output Channels | 7.1 channels |
| Component For | PC |
| Motherboard Chipset | Intel® B360 |
| Motherboard Chipset Family | Intel |
| Motherboard Form Factor | ATX |
| Power Source Type | ATX |
| Windows Operating Systems Supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64 |
Graphics
| Graphics Card | HD Graphics |
|---|---|
| Graphics Card Family | Intel |
| Maximum Resolution | 4096 x 2160 pixels |
| Parallel Processing Technology Support | 2-Way CrossFireX |
Internal I/O
| Atx Power Connector (24-Pin) | Yes |
|---|---|
| Chassis Intrusion Connector | Yes |
| Cpu Fan Connector | Yes |
| Eps Power Connector (8-Pin) | Yes |
| Front Panel Audio Connector | Yes |
| Number Of Chassis Fan Connectors | 2 |
| Number Of Com Connectors | 1 |
| Number Of Sata Iii Connectors | 6 |
| S/Pdif Out Connector | Yes |
| Usb 2.0 Connectors | 1 |
| Usb 3.2 Gen 1 (3.1 Gen 1) Connectors | 1 |
Logistics data
| Harmonized System (Hs) Code | 84733020 |
|---|
Memory
| Ecc сOmpatibility | Non-ECC |
|---|---|
| Maximum Internal Memory | 64 GB |
| Memory Channels | Dual-channel |
| Memory Slots Type | DIMM |
| Supported Memory Clock Speeds | 2133,2400,2666 MHz |
| Supported Memory Types | DDR4-SDRAM |
| Unbuffered Memory | Yes |
Network
| Ethernet Lan | Yes |
|---|---|
| Lan Controller | Intel® I219-V |
Other features
| Analog Audio Output | 3 |
|---|---|
| Other Features | ASUS Turbo LAN Utility TUF LANGuard ASUS SafeSlot: Protect your graphics card Investment ASUS ESD Guard: Enhanced ESD protection ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability! ASUS Overvoltage Protection: World-class circuit-protecting power design ASUS DIGI + VRM: 4+2+1 Phase digital power design EPU TUF Components (Choke, Cap. & MOSFET; certified by military-standard) Aura Lighting Control Aura RGB Strip Headers AI Suite 3 Ai Charger Stylish Fanless Design Heat-sink solution ASUS Fan Xpert 4 Core ASUS CrashFree BIOS 3 ASUS EZ Flash 3 ASUS UEFI BIOS EZ Mode ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) ASUS Q-Slot ASUS Q-DIMM |
| Utilities Included | Yes |
Packaging content
| Cables Included | SATA |
|---|---|
| Drivers Included | Yes |
| Manual | Yes |
Processor
| Compatible Processor Series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Pentium® |
|---|---|
| Intel Core I3/I5/I7/I9 Series | i3-8xxx, i5-8xxx, i7-8xxx |
| Maximum Number Of Smp Processors | 1 |
| Processor Manufacturer | Intel |
| Processor Socket | LGA 1151 (Socket H4) |
Processor special features
| Intel® Clear Video Hd Technology (Intel® Cvt Hd) | Yes |
|---|---|
| Intel Extreme Memory Profile (Xmp) | Yes |
| Intel® Insider™ | Yes |
| Intel® Intru™ 3d Technology | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Turbo Boost Technology | 2.0 |
Rear panel I/O ports
| Ethernet Lan (Rj-45) Ports | 1 |
|---|---|
| Hdmi Ports Quantity | 1 |
| Hdmi Version | 1.4b |
| Ps/2 Ports Quantity | 1 |
| Usb 2.0 Ports Quantity | 4 |
| Usb 3.2 Gen 1 (3.1 Gen 1) Type-C Ports Quantity | 1 |
| Usb 3.2 Gen 2 (3.1 Gen 2) Type-A Ports Quantity | 2 |
| Vga (D-Sub) Ports Quantity | 1 |
Weight & dimensions
| Depth | 244 mm |
|---|---|
| Width | 305 mm |
