Home / Processors / DELL 2 x Intel Xeon E5-4620 v4 processor 2.1 GHz 25 MB
DELL · MPN 374-BBMK · DELL 2 x Intel Xeon E5-4620 v4 processor 2.1 GHz 25 MB
DELL 2 x Intel Xeon E5-4620 v4 processor 2.1 GHz 25 MB
- Processor Family
- Intel® Xeon® E5 v4
- Processor Model
- E5-4620V4
- Processor Cores
- 10
- Processor Socket
- LGA 2011-v3
Specifications
Features
| Cpu Configuration (Max) | 4 |
|---|---|
| Embedded Options Available | No |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Market Segment | Server |
| Maximum Number Of Pci Express Lanes | 40 |
| Pci Express Slots Version | 3.0 |
| Physical Address Extension (Pae) | 46 bit |
| Scalability | 4S |
| Supported Instruction Sets | AVX 2.0 |
| Thermal Monitoring Technologies | Yes |
Graphics
| Discrete Graphics Card | No |
|---|---|
| Discrete Graphics Card Model | Not available |
| On-Board Graphics Card | No |
| On-Board Graphics Card Model | Not available |
Memory
| Ecc | Yes |
|---|---|
| Maximum Internal Memory Supported By Processor | 1.54 TB |
| Memory Channels | Quad-channel |
| Memory Types Supported By Processor | DDR4-SDRAM |
Operational conditions
| Tcase | 79 °C |
|---|
Other features
| Compatibility | - PowerEdge FC830 - PowerEdge M830 - Poweredge R830 |
|---|
Processor
| Bus Type | QPI |
|---|---|
| Component For | Server/workstation |
| Memory Bandwidth Supported By Processor (Max) | 68 GB/s |
| Number Of Qpi Links | 2 |
| Processor Base Frequency | 2.1 GHz |
| Processor Boost Frequency | 2.6 GHz |
| Processor Cache | 25 MB |
| Processor Codename | Broadwell |
| Processor Cores | 10 |
| Processor Family | Intel® Xeon® E5 v4 |
| Processor Lithography | 14 nm |
| Processor Model | E5-4620V4 |
| Processor Operating Modes | 64-bit |
| Processor Series | Intel® Xeon® E5-4600 v4 Family |
| Processor Socket | LGA 2011-v3 |
| Processor Threads | 20 |
| Stepping | M0 |
| System Bus Rate | 8 GT/s |
| Thermal Design Power (Tdp) | 105 W |
Processor special features
| Conflict-Free Processor | Yes |
|---|---|
| Enhanced Intel Speedstep Technology | Yes |
| Intel 64 | Yes |
| Intel® Aes New Instructions (Intel® Aes-Ni) | Yes |
| Intel Flex Memory Access | No |
| Intel® Hyper Threading Technology (Intel® Ht Technology) | Yes |
| Intel Instruction Replay Technology | No |
| Intel® Os Guard | Yes |
| Intel® Secure Key | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Tsx-Ni | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Virtualization Technology For Directed I/O (Vt-D) | Yes |
| Intel Virtualization Technology (Vt-X) | Yes |
| Intel Vt-X With Extended Page Tables (Ept) | Yes |
